High quality low price all-hydraulic 14 Inch river sand Cutter Suction Dredger

FOB Reference Price:Get Latest Price
US $800,000-1,100,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Cutter Suction Dredger
Power Type:
Diesel
Dredging Depth:
15 m
Draught:
200 cm
Place of Origin:
China (Mainland)
Brand Name:
REALMINING
Model Number:
RM
Dimension(L*W*H):
15.2*7.2*1.9m
Weight:
Dredger Size
Certification:
ISO9001
Application:
Sand Dredging
Usage:
Dredging Mud
Product name:
Sand Dredger Machine
Name:
Sand Pump Suction Dredger
Discharging distance:
2500M
Color:
Customer's Request
Working capacity:
500m3/h
Water flow:
800-8000 M3/hour
Structure:
Dismantle
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
500 Set/Sets per Year
Packaging & Delivery
Packaging Details
Diassembled and fit into containers
Port
Qingdao
Lead Time :
45-150days after down payment
Product Description



Cutter suction dredgers, characterized by strong geographical environment adaptability, a simple structure, easy maintenance, reliable performance, long service life, low costs and large workload (1,000 to 4,000 cubic meters per day) are ideal choice for sand field and river sand mining. It can also be used in salt mining in salt lakes, offshore and river dredging, hard riverbed mining, waterway improvement and development. Dug sand after screening and separation is pure and inclusion-free, which is an ideal choice for the building industry.

Cutter suction dredgers can be installed with ore dressing equipment to extract gold, iron ore and other minerals, featuring a high degree of automation, high extraction accuracy and large processing capacity. It leads the industry both at home and abroad.



Specification



Item/model

RMC200

RMC250

RMC300

RMC350

RMC450

RMC500

RMC600

Working load

800m3/h

1500m3/h

2500m3/h

3000m3/h

4000m3/h

6000m3/h

8000m3/h

L*B*H m

15.5*7.2*1.9

15.5*7.2*1.9

21*7.5*2m

23.5*8*2.4m

23.5*8*2.4m

26*5.8*1.6

29*9*2.7m

Max.Dredging depth

8m

10m

15m

15m

15m

15m

15m

Average draught

1.3

1.3m

1.4

1.6

1.6

1.7m

2m

Discharge distance

600m

800m

1200m

1500m

1500m

2000m

2500m

Diameter suction/discharge pipe

325/300mm

377/377mm

460/420mm

550/500mm

580/550mm

680/650mm

810/780mm

Diameter of

cutter head

Φ1300mm

Φ1300mm

Φ1500mm

Φ1700mm

Φ1700mm

Φ2200mm

Φ2450mm

Main

engine power

258kw

330kw

650kw

1000kw

1200kw

1580kw

2400kw

Diameter

oil cyclinda

100mm

100mm

160mm

160mm

160mm

200mm

250mm

Emergency genset power

15kw

15kw

15kw

24kw

24kw

30kw

30kw

Max. oil consumption

51.6kg/h

66kg/h

130kg/h

266kg/h

266kg/h

396kg/h

600kg/h

MOQ

1

1

1

1

1

1

1

Valid time

4months

Port

Qingdao port

Tianjin port

delivery time

45

60

70

90

100

120

150

Container40'

*40*4.5

*40*4.5

*Bulk Cargo

*Bulk Cargo

*Bulk Cargo

**Bulk Cargo

*Bulke Cargo

Product Overviews









Packaging & Shipping

Shipping need 45-150days according to different machine

Disassembled and fit into 40' containers

If there have any needs,pls feel free to contact us.
