Portable Africa diamond and gold recovery washing plant
- Condition:
-
New
- Type:
-
Gravity Separator, Belt Type
- Production Capacity:
-
98%
- Place of Origin:
-
Shandong, China (Mainland)
- Brand Name:
-
REALMINING
- Model Number:
-
HPC-10
- Voltage:
-
Clients Local Standard
- Power(W):
-
7.5kw
- Dimension(L*W*H):
-
5.63*1.76*1.8m
- Weight:
-
1700kg
- Certification:
-
ISO9001:2008
- Application:
-
Alluvial Gold Or Gemstone Recovery
- Color:
-
Customers' Requirements
- Installation:
-
Engineer Guide
- Capacity:
-
Around 10tons per hour
- Material:
-
Steel
- Feeding size:
-
0-230mm
- Customer Visit:
-
Very Welcome
- Manufacturer:
-
Sure
- Shipment:
-
one 20feet container
- After-sales Service Provided:
-
No overseas service provided
- Warranty:
-
1 Year
- Supply Ability:
- 50 Set/Sets per Month
- Packaging Details
- nude with protect measure, washing plant in one 20' container
- Port
- Qingdao
A compact, mobile concentrator, the HPC-15 is designed for exploration and bulk sampling, integrating all components into a single trailer-mounted unit. Easy to move and operate, the versatile HPC-15 offers an unbeatable recovery rate down to ultra-fine particles to guarantee accurate and scalable sampling. The HPC-10 and HPC-15 are similar machines – the key difference is that the HPC-10 has a Manual Feed Chute where the HPC-15 is equipped with an integrated Feed Conveyor.
Feed material:
Maximum: 6” (150 mm) minus material. Recommended: 3” (75mm) minus.
Trommel
Scrubbing & Screening Trommel is 2.8m long with 0.4m diameter and 1.65 m 2-stage Scrubber. Screen is 8mm.
Dimensions:
Length 5.63m, Width 1.76m, Height 1.80m, Weight: 1,700 kg
Manning:
1 equipment operator required.
Packaging the trommel screen spare parts like screen siece by wooden boxes protect damage and loss during transportation ;
Delivery machine by 20-foot & 40-foot container according to trommel gold wash plant total size ;
Be responsible contact with shipping agent arrange machine shipping ,client can also contact shipping agent by himself to delivery our gold wash plant .
More than 20years experience in mining field,if there have any needs,please feel free to contact us.
